Immich
| URL | https://pics.garlondindustries.com |
|---|---|
| Host | bay-21.lan |
| Authentication | OAuth (Authelia) |
| Backup | TO DO |
Setup
OAuth
external library
Configured dedicated NFS share as external library. This share is also configured as global external storage in Nextcloud, accessibhle to all authenticated users .
The external library can only be owned by one user - there is no direct way to share external libraries between users (yet). As a workaround, can add other users as sharing partners (they will see sharing user's timeline including external libraries, excluding locked folders, archive and deleted), and/or photos from external library can be put (scripted?) into shared albums. Difference is users can edit shared albums, while they only have read-only access to partner-shared photos.
Unraid NFS share:
- nc-immich
- private
- 10.0.0.55(rw,sync,all_squash,anonuid=5010,anongid=5010)
- 10.0.0.44(rw,sync,all_squash,anonuid=5010,anongid=5010)
External library owned by admin user. Cron-based scans running every 15 minutes.
Setup
docker-compose:
OAuth
Authelia create client secret: https://www.authelia.com/integration/openid-connect/frequently-asked-questions/#how-do-i-generate-a-client-identifier-or-client-secret
$ docker run --rm authelia/authelia:latest authelia crypto hash generate pbkdf2 --variant sha512 --random --random.length 72 --random.charset rfc3986 Random Password: [...] Digest: $pbkdf2-sha512$[...]
Add client config (/mnt/docker/custom_config/authelia/configuration.yml) - skipping schema extension for immich_quota and immich_role for now. To add those see https://immich.app/docs/administration/oauth/:
- id: 'immich' secret: $pbkdf2-sha512$$pbkdf2-sha512$[...] public: false require_pkce: false redirect_uris: - 'https://pics.garlondindustries.com/auth/login' - 'https://pics.garlondindustries.com/user-settings' - 'pics.garlondindustries.com:///oauth-callback' scopes: - 'openid' - 'profile' - 'email' #- 'immich_scope' #claims_policy: 'immich_policy' response_types: - 'code' grant_types: - 'authorization_code' id_token_signed_response_alg: 'RS256' userinfo_signed_response_alg: 'RS256' token_endpoint_auth_method: 'client_secret_post'
Reverse Proxy
Defined proxy host https://pics.garlondindustries.com.
Needed to enable WebSocket support - otherwise, immich would show “Server Offline” and “unknown” for version info as it seems to check against public URL via WebSocket.
